Features:

• Low pressure drops, ensuring high energy savings.
• High retention capability (99.999%).
• Extremely purified compressed air with low operating costs.
• Large capacity reservoir for high condensate volume.
• Drainage layer for effective operation.
• The closure provided by the seal cannot be opened while the filter is under pressure.
• Inlet air temperature of up to 100°C (Max.).
• Filtration grades comply with ISO8573-1 standards.

Housing:

• Pressure die-cast aluminum housing.
• Chromated for protection against corrosion.
• Powder coating process with zinc-based corrosion inhibition primer and epoxy polyester powder.
• Salt spray test conducted in a saline fog (5% NaCl) at 37°C for 72 hours.
• NBR 70A material for enhanced durability.
• Hydrogenated Nitrile O-ring with superior mechanical properties, high strength, and temperature resistance (-40°C to 100°C).

Durable Chemical-Resistant End Caps:

Injection molded from nylon and bonded to the filter core with high-strength, two-part polyurethane potting resin for maximum durability.

Standard Reference Conditions:

• Ambient temperature: 45°C
• Working pressure: 7 Kg/cm²
• Inlet air temperature: 100°C

Maximum Working Conditions:

• Pressure: 16 Kg/cm²
• Inlet air temperature: 100°C

Filtration Grades:

• P = 3µ (Class 3 ISO8573.1)
• F = 1µ solid / 1 mg/m³ oil (Class 2 ISO8573.1)
• H = 0.01µ solid / 0.01 mg/m³ oil (Class 1 ISO8573.1)

Filter Specifications:
